CSS3 3D Transforms
CSS3 allows you to format your elements using 3D transformations.

Mouse over the elements below to see the difference between a 2D and a 3D transformation:

2D rotate
3D rotate
Browser Support for 3D Transforms
The numbers in the table specify the first browser version that fully supports the property.

Numbers followed by -webkit-, -moz-, or -o- specify the first version that worked with a prefix.

Property
transform 36.0
12.0 -webkit- 10.0 16.0
10.0 -moz- 9.0
4.0 -webkit- 23.0
15.0 -webkit-
transform-origin
(three-value syntax) 36.0
12.0 -webkit- 10.0 16.0
10.0 -moz- 9.0
4.0 -webkit- 23.0
15.0 -webkit-
transform-style 36.0
12.0 -webkit- 11.0 16.0
10.0 -moz- 9.0
4.0 -webkit- 23.0
15.0 -webkit-
perspective 36.0
12.0 -webkit- 10.0 16.0
10.0 -moz- 9.0
4.0 -webkit- 23.0
15.0 -webkit-
perspective-origin 36.0
12.0 -webkit- 10.0 16.0
10.0 -moz- 9.0
4.0 -webkit- 23.0
15.0 -webkit-
backface-visibility 36.0
12.0 -webkit- 10.0 16.0
10.0 -moz- 9.0
4.0 -webkit- 23.0
15.0 -webkit-
CSS3 3D Transforms
In this chapter you will learn about the following 3D transformation methods:

rotateX()
rotateY()
rotateZ()
The rotateX() Method


The rotateX() method rotates an element around its X-axis at a given degree:

Example
div {
    -webkit-transform: rotateX(150deg); /* Safari */
    transform: rotateX(150deg);
}
»
The rotateY() Method


The rotateY() method rotates an element around its Y-axis at a given degree:

Example
div {
    -webkit-transform: rotateY(130deg); /* Safari */
    transform: rotateY(130deg);
}
»
The rotateZ() Method
The rotateZ() method rotates an element around its Z-axis at a given degree:

Example
div {
    -webkit-transform: rotateZ(90deg); /* Safari */
    transform: rotateZ(90deg);
}
»
Test Yourself with Exercises!
Exercise 1 »  Exercise 2 »  Exercise 3 »

CSS3 Transform Properties
The following table lists all the 3D transform properties:

Property Description
transform Applies a 2D or 3D transformation to an element
transform-origin Allows you to change the position on transformed elements
transform-style Specifies how nested elements are rendered in 3D space
perspective Specifies the perspective on how 3D elements are viewed
perspective-origin Specifies the bottom position of 3D elements
backface-visibility Defines whether or not an element should be visible when not facing the screen
3D Transform Methods
Function Description
matrix3d
(n,n,n,n,n,n,n,n,n,n,n,n,n,n,n,n) Defines a 3D transformation, using a 4x4 matrix of 16 values
translate3d(x,y,z) Defines a 3D translation
translateX(x) Defines a 3D translation, using only the value for the X-axis
translateY(y) Defines a 3D translation, using only the value for the Y-axis
translateZ(z) Defines a 3D translation, using only the value for the Z-axis
scale3d(x,y,z) Defines a 3D scale transformation
scaleX(x) Defines a 3D scale transformation by giving a value for the X-axis
scaleY(y) Defines a 3D scale transformation by giving a value for the Y-axis
scaleZ(z) Defines a 3D scale transformation by giving a value for the Z-axis
rotate3d(x,y,z,angle) Defines a 3D rotation
rotateX(angle) Defines a 3D rotation along the X-axis
rotateY(angle) Defines a 3D rotation along the Y-axis
rotateZ(angle) Defines a 3D rotation along the Z-axis
perspective(n) Defines a perspective view for a 3D transformed element
